<h2>Content of delivery</h2> <p>The delivery includes the items listed below. They are sufficient to replace the damaged motor with a new one.</p> <ul> <li>1 x Operator for swing gates Sommer twist 200E</li> <li>2 x Mounting bolts and nuts</li> <li>User manual</li> </ul></p> <p>The mounting bracket motor-post is not included in delivery. If you also need the mounting bracket, please don't hesitate to contact us before purchasing.</p>

Technical specification

Power supply - engine	24V
Maximal weight of gate leaf	300 kg
Maximal length of gate leaf	2.5 m
Duty cycle	15%
Protection rating	IP44
Operating temperature	-30°C ÷ +70°C

Allowable length and weight of single gate leaf

The chart below shows the relationship between the maximum length of a single gate leaf and its weight, which allows for the trouble-free installation of this motor. Values supported by the drive are located in the gray area below the black line. If any of your gate's values (length or weight of a single wing) exceed this area, then installing this motor is not recommended, and you should consider purchasing a different model.
